HONGLITRONIC

Date: 2017-07-05

Case name: HONGLITRONIC

鸿利智汇

Hongli Zhihui Group (HONGLITRONIC) Stock Code: 300219——Hongli Zhihui was founded in 2004 with registered capital of 710 million RMB, stock code: 300219. The headquarters is located in Guangzhou. Hongli Zhihui is one of the high and new technology manufacturer, specialized in production and development of SMD LEDs, COB LEDs, High Power LEDs, Automotive LEDs, UV LEDs, LAMP LEDs, Infrared LEDs etc.
