SMIDA automatic laser cutting machine CT-UV015D

Release time: 2017 - 08 - 09

Model CT-UV015DProduct Smida automatic UV laser cutting machineApplication COB depaneling, fingerprint identification module cutting, CVL,FPC, RF cutting,Laser 355nm wavelength ,SPI, Newport,AOCLaser power1-15W adjustableLaser pulse frequency 30KHZ-200KHZ adjustableOutput pulse width ˂ 10nsLaser warranty 12 monthsPumping source life20000 hourLaser thickness ≦1.5mmGalvanometer system SCANLAB-basiCube 10Galvanometer scan range50 x 50 mmCutting efficiency 1000mm/S cutting thickness affect the eff...

● The high-performance, multi-purpose UV laser cutting machine apply non-contact working platform and equipped with high speed digital galvanometer to avoid the hidden damage caused by the stress processing of tool and molds; ● The function of CCD automatic positioning compensation deformation can be more suitable for product deformation, and the function of high configured automatic edge cutting automatic compensation can adapt to the deviation caused by stress processing of previous process, and the cutting edge is more smooth. ● With the feature of short wavelength,...

More>>
SMIDA Automatic LASER MARKING MACHINE

Release time: 2017 - 07 - 05

MODELCS-60DVMin marking character0.1mm (example based on PPA bracket)productFully automatic laser marking machineMax marking accuracy0.1 mm(example based on PPA bracket, equipped CCD)Marking range100x100mm to 200x200mmpower2500WMarking power3W-10WPower supply220V/60HZApplicable bracket49-75mm width, length 120-180mmdimension2044x 2000x1000 mmApplicable materialPPA,EMC,PCT,ceramic substrate,aluminum substrateWeight400kgWork efficiency300-1000pcs/hour (single laser, 14x 28 2835, PPA)1、 No further notice if there is appearance,specification change 2、Do not put danger or hazardous material3、...

【Introduction】Equipped with high quality UV laser marking system, able to complete marking task accurately and effectively, the marking character is clear and beautifulAble to marking code in serial number or jump code User can choose laser marking machine with single or double laser, and optional CCD visual alignment system. According to the different requirements of customers, there are a variety of machine configurations to choose.The minimum marking characters are up to 0.1mm, with marking accuracy up to ± 0.01mm, which perfectly meets the marking needs of small particle product.Ultra...

More>>
SMIDA green laser marking machine 07LV series

Release time: 2017 - 07 - 06

Model07LVSingle pulse energy220 ujBeam modeTEM00(m2˂1.3)ProductManual green laser marking machineSingle pulse stability˂3% rmsspot diameter0.7mmPulse width18nsPoint stability˂500uradSpot roundness90% Laser wavelength532 nmAverage power7 WSpot divergence angle˂2mradRepeat frequency10HZ-150KHZAverage power stability˂ ±3% over 24 hoursWork ambient temperature15-30 ℃Cooling methodAir coolingWorking voltage90-260VACStorage temperature-10-50 ℃ Polarization statestraightPolarization ratio100:11、 No further notice if there is appearance,specification change 2、 Do not put dang...

Green laser output wave length is 532nm, compared to CO2 laser and fiber laser, its thermal radiation effective is smaller, is a relative cold light source.Green laser is typically used in crystal or acrylic marking and engravingAble to achieve clear marking on plastic material, and high quality marking on silicon material , gold ,silver and other high reflective material.

More>>
SMIDA TMV-700TT vacuum deaeration mixer

Release time: 2017 - 07 - 06

【Introduction】TMV-700TT vacuum deaeration mixer is a planetary centrifugal mixer mainly applied in mixing fluid or powder material and reach deaeration effect.Rotation/Revolution while working with high power vacuum pump,equipment can stir the material evenly in few seconds or few minutes,stir and vacuum complete at the same timeMixing capacity varies from a few grams up to 700 grams by using different containers, meet the requirement from laboratory use to volume productionUp to 10 preset programs(Can be customized), every program can be divided to 5 segment, each segment with different ...

More>>
SMIDA TMV-1500TT vacuum deaeration mixer

Release time: 2017 - 07 - 06

【Introduction】TMV-1500TT vacuum deaeration mixer is a planetary centrifugal mixer mainly applied in mixing fluid or powder material and reach deaeration effect. Rotation/Revolution while working with high power vacuum pump,equipment can stir the material evenly in few seconds or few minutes,stir and vacuum complete at the same timeMixing capacity varies from a few grams up to 1500 grams by using different containers, meet the requirement from laboratory use to volume production Up to 10 preset programs(Can be customized), every program can be divided to 5 segment, each segment w...

More>>

More>>

OSRAM

Date: 2017-07-05

Case name: OSRAM

欧司朗照明

Osram Opto is a wholly owned subsidiary of Siemens AG and one of the two largest light source manufacturers in the world. Its headquarters is located in the German city of Munich. OSRAM opened production bases in Guangzhou, Foshan and Kunshan respectively in mainland China, nearly 40 sales offices in mainland China, nearly 8,000 employees in China and an office in Taiwan. Its subsidiary Foshan Electrical and Lighting Co., Ltd., a company listed in Shenzhen Stock Exchange.
