Jingdingyuan Optoelectronics

Date: 2017-07-05

Case name: Jingdingyuan Optoelectronics

深圳市晶鼎源光电科技有限公司

Shenzhen Jingdingyuan Optoelectronics Technology Co., Ltd. is a wholly-owned subsidiary of Tianbao Investment and Development Corporation. It was established in September 2009 with a registered capital of 30 million. The first phase of investment is 80 million and the total investment is over 200 million. The company is a research and development, production and sales of integrated high-tech optoelectronic enterprises, dedicated to the manufacture of light-emitting diodes, LED lighting. The main products is side light (020,010), TOP LED (3014,3020), broadly applied to a variety of display backlight and lighting applications and lighting projects.

Previous:Smalite Semiconductor Next: None
