Product name SMIDA Automatic LASER MARKING MACHINE
Listing time:2017-07-05

SMIDA Automatic LASER MARKING MACHINE

Product description: 【Introduction】Equipped with high quality UV laser marking system, able to complete marking task accurately and effectively, the marking character is clear and beautifulAble to marking code in serial number or jump code User can choose laser marking machine with single or double laser, and optional CCD visual alignment system. According to the different requirements of customers, there are a variety of machine configurations to choose.The minimum marking characters are up to 0.1mm, with marking accuracy up to ± 0.01mm, which perfectly meets the marking needs of small particle product.Ultra-high material loading efficiency, with a single laser marking machine,able to load 300-2000 pieces of film per hour.Equipped with a strong vacuum suction system, the material only touches the silicon soft suction cups to ensure that the material will not be damaged.Equipped with high-precision color photoelectric sensor, accurate-distinguished material and isolation paper, it will avoid misuse and suck the material into the waste paper box.Equipped with double hopper feeding system, it can replace the material without stop the machines, which improves the work efficiency.Equipped with 8 box feeding system, which greatly prolongs the replacement cycle of material box and reduces the frequency of manual replacement of material box【Application industrial】Camera module, fingerprint module, PCB/FPC, stainless steel,communication product, ceramic, electronic components, sapphire, tempered glass  【Marking effect】   PCB：3030 LED
Fabric: MODELCS-60DVMin marking character0.1mm (example based on PPA bracket)productFully automatic laser marking machineMax marking accuracy0.1 mm(example based on PPA bracket, equipped CCD)Marking range100x100mm to 200x200mmpower2500WMarking power3W-10WPower supply220V/60HZApplicable bracket49-75mm width, length 120-180mmdimension2044x 2000x1000 mmApplicable materialPPA,EMC,PCT,ceramic substrate,aluminum substrateWeight400kgWork efficiency300-1000pcs/hour (single laser, 14x 28 2835, PPA)1、 No further notice if there is appearance,specification change  2、Do not put danger or hazardous material3、To protect the effect of the machine, need to put double bracket of the box number, and must be placed symmetrically4、SMIDA reserve the final interpretation of our product. .
Category:
Types of: SMIDA Automatic LASER MARKING MACHINE
Model:

思迈达全自动激光打标机CS-60DV
  • Introduction
  • Dimension
  • Specification

【Introduction】

Equipped with high quality UV laser marking system, able to complete marking task accurately and effectively, the marking character is clear and beautiful

Able to marking code in serial number or jump code

User can choose laser marking machine with single or double laser, and optional CCD visual alignment system.

According to the different requirements of customers, there are a variety of machine configurations to choose.

The minimum marking characters are up to 0.1mm, with marking accuracy up to ± 0.01mm, which perfectly meets the marking needs of small particle product.

Ultra-high material loading efficiency, with a single laser marking machine,able to load 300-2000 pieces of film per hour.

Equipped with a strong vacuum suction system, the material only touches the silicon soft suction cups to ensure that the material will not be damaged.

Equipped with high-precision color photoelectric sensor, accurate-distinguished material and isolation paper, it will avoid misuse and suck the material into the waste paper box.

Equipped with double hopper feeding system, it can replace the material without stop the machines, which improves the work efficiency.

Equipped with 8 box feeding system, which greatly prolongs the replacement cycle of material box and reduces the frequency of manual replacement of material box


【Application industrial】

Camera module, fingerprint module, PCB/FPC, stainless steel,communication product, ceramic, electronic components, sapphire, tempered glass





【Marking effect】

SMIDA Automatic LASER MARKING MACHINE



SMIDA Automatic LASER MARKING MACHINE



 SMIDA Automatic LASER MARKING MACHINE


PCB：

思迈达全自动激光打标机CS-60DV


3030 LED

思迈达全自动激光打标机CS-60DV




思迈达全自动激光打标机CS-60DV


MODEL

CS-60DV

Min marking character

0.1mm (example based on PPA bracket)

product

Fully automatic laser marking machine

Max marking accuracy

0.1 mm(example based on PPA bracket, equipped CCD)

Marking range

100x100mm to 200x200mm

power

2500W

Marking power

3W-10W

Power supply

220V/60HZ

Applicable bracket

49-75mm width, length 120-180mm

dimension

2044x 2000x1000 mm

Applicable material

PPA,EMC,PCT,ceramic substrate,aluminum substrate

Weight

400kg

Work efficiency

300-1000pcs/hour (single laser, 14x 28 2835, PPA)



1、 No further notice if there is appearance,specification change

2、Do not put danger or hazardous material

3、To protect the effect of the machine, need to put double bracket of the box number, and must be placed symmetrically

4、SMIDA reserve the final interpretation of our product. .
