![SMIDA automatic laser cutting machine CT-UV015D]( "SMIDA automatic laser cutting machine CT-UV015D")
● The high-performance, multi-purpose UV laser cutting machine apply non-contact working platform and equipped with high speed digital galvanometer to avoid the hidden damage caused by the stress processing of tool and molds; ● The function of CCD automatic positioning compensation deformation can be more suitable for product deformation, and the function of high configured automatic edge cutting automatic compensation can adapt to the deviation caused by stress processing of previous process, and the cutting edge is more smooth. ● With the feature of short wavelength, high energy density, small heat influence range,The 355nm UV laser able to achieve cold process by destroy material molecular structure quickly，eliminate the cooling water, cleansing water, cutting and dust along with mechanical processing. ● It can identify DXF and GERBER files and eliminate molds,achieve rapid prototyping, cutting and drilling, especially suitable for the processing of complex, sophisticated and difficult products. ● The design of duplex station saves the time of replacing the material by manual or automatic manipulator, which exceeds 30% of the laser efficiency of the same type of equipment in the market. ● With the design of flight optical path, the high-speed mobile gantry structure, can be customized to carry automatic loading and unloading machine, or match with SMT line ● Mobile camera module sub-board, fingerprint identification module cutting, TF card type memory card, FPC flexible circuit board; cutting any product within thickness of 1MM has no burr ,high precision and small heat affected range; ● Self-developed control software based on WINDOWS, fool operation, simple and quick.【Laser cutting sample effect】Camera COBPCBPCBFingerprint identification moduleCVLFPC
Member price:
￥
0
RMB
Market price:
￥
0
RMB
Release time:
2017
-
08
-
09
-
![SMIDA Automatic LASER MARKING MACHINE]( "SMIDA Automatic LASER MARKING MACHINE")
【Introduction】Equipped with high quality UV laser marking system, able to complete marking task accurately and effectively, the marking character is clear and beautifulAble to marking code in serial number or jump code User can choose laser marking machine with single or double laser, and optional CCD visual alignment system. According to the different requirements of customers, there are a variety of machine configurations to choose.The minimum marking characters are up to 0.1mm, with marking accuracy up to ± 0.01mm, which perfectly meets the marking needs of small particle product.Ultra-high material loading efficiency, with a single laser marking machine,able to load 300-2000 pieces of film per hour.Equipped with a strong vacuum suction system, the material only touches the silicon soft suction cups to ensure that the material will not be damaged.Equipped with high-precision color photoelectric sensor, accurate-distinguished material and isolation paper, it will avoid misuse and suck the material into the waste paper box.Equipped with double hopper feeding system, it can replace the material without stop the machines, which improves the work efficiency.Equipped with 8 box feeding system, which greatly prolongs the replacement cycle of material box and reduces the frequency of manual replacement of material box【Application industrial】Camera module, fingerprint module, PCB/FPC, stainless steel,communication product, ceramic, electronic components, sapphire, tempered glass 【Marking effect】 PCB：3030 LED
Member price:
￥
0
RMB
Market price:
￥
0
RMB
SMIDA Automatic LASER MARKING MACHINE
Release time:
2017
-
07
-
05
-
![SMIDA TMV-700TT vacuum deaeration mixer]( "SMIDA TMV-700TT vacuum deaeration mixer")
【Introduction】TMV-700TT vacuum deaeration mixer is a planetary centrifugal mixer mainly applied in mixing fluid or powder material and reach deaeration effect.Rotation/Revolution while working with high power vacuum pump,equipment can stir the material evenly in few seconds or few minutes,stir and vacuum complete at the same timeMixing capacity varies from a few grams up to 700 grams by using different containers, meet the requirement from laboratory use to volume productionUp to 10 preset programs(Can be customized), every program can be divided to 5 segment, each segment with different mixing time and speed, able to deal with different types of the materials.Max rotation speed is 2500rpm, high viscosity material can be mixed evenly .The equipment is suitable for customer who have high volume demand. Single cup can mix up to 700g, double cup can mix up to 1400gThe key parts are all from industrial famous brands from home and abroad, to guarantee the stability of equipment under long time and high load operation【 Characteristic】 Max mixing capacity 370ml/450gThe equipment stir the material under vacuum status through high-speed revolution/rotation (max 2500RPM) to achieve deaeration effect. The equipment is non-contact stirringHigh viscosity resin can be stirred and achieve ideal deaeration effect in short time ,and material no overflowHigh stability performanceTips:No further notice if there is appearance and specification change.The product is non-explosive proof ,do not stir danger or hazardous material【Mixing effect】
Member price:
￥
0
RMB
Market price:
￥
0
RMB
SMIDA TMV-700TT vacuum deaeration mixer
Release time:
2017
-
07
-
06
