The latest products / The latest products
  • Release time: 2017 - 08 - 09
    Model  CT-UV015DProduct   Smida automatic UV laser cutting machineApplication COB depaneling, fingerprint identification module cutting, CVL,FPC, RF cutting,Laser     355nm wavelength ,SPI, Newport,AOCLaser power1-15W adjustableLaser pulse frequency 30KHZ-200KHZ adjustableOutput pulse width ˂  10nsLaser warranty 12 monthsPumping source life20000 hourLaser thickness ≦1.5mmGalvanometer  system  SCANLAB-basiCube 10Galvanometer scan range50 x 50 mmCutting efficiency   1000mm/S cutting thickness affect the eff...
    ● The high-performance, multi-purpose UV laser cutting machine apply non-contact working platform and equipped with high speed digital galvanometer to avoid the hidden damage caused by the stress processing of tool and molds; ● The function of CCD automatic positioning compensation deformation can be more suitable for product deformation, and the function of high configured automatic edge cutting automatic compensation can adapt to the deviation caused by stress processing of previous process, and the cutting edge is more smooth. ● With the feature of short wavelength,...
  • Release time: 2017 - 07 - 05
    MODELCS-60DVMin marking character0.1mm (example based on PPA bracket)productFully automatic laser marking machineMax marking accuracy0.1 mm(example based on PPA bracket, equipped CCD)Marking range100x100mm to 200x200mmpower2500WMarking power3W-10WPower supply220V/60HZApplicable bracket49-75mm width, length 120-180mmdimension2044x 2000x1000 mmApplicable materialPPA,EMC,PCT,ceramic substrate,aluminum substrateWeight400kgWork efficiency300-1000pcs/hour (single laser, 14x 28 2835, PPA)1、 No further notice if there is appearance,specification change  2、Do not put danger or hazardous material3、...
    【Introduction】Equipped with high quality UV laser marking system, able to complete marking task accurately and effectively, the marking character is clear and beautifulAble to marking code in serial number or jump code User can choose laser marking machine with single or double laser, and optional CCD visual alignment system. According to the different requirements of customers, there are a variety of machine configurations to choose.The minimum marking characters are up to 0.1mm, with marking accuracy up to ± 0.01mm, which perfectly meets the marking needs of small particle product.Ultra...
  • Release time: 2017 - 07 - 06
    Model07LVSingle pulse energy220 ujBeam modeTEM00(m2˂1.3)ProductManual green laser marking machineSingle pulse stability˂3% rmsspot diameter0.7mmPulse width18nsPoint stability˂500uradSpot roundness90% Laser wavelength532 nmAverage power7 WSpot divergence angle˂2mradRepeat frequency10HZ-150KHZAverage power stability˂ ±3% over 24 hoursWork ambient temperature15-30 ℃Cooling methodAir coolingWorking voltage90-260VACStorage temperature-10-50 ℃ Polarization statestraightPolarization ratio100:11、 No further notice if there is appearance,specification change  2、 Do not put dang...
    Green laser output wave length is 532nm, compared to CO2 laser and fiber laser, its thermal radiation effective is smaller, is a relative cold light source.Green laser is typically used in crystal or acrylic marking and engravingAble to achieve clear marking on plastic material, and high quality marking on silicon material , gold ,silver and other high reflective material.
  • Release time: 2017 - 07 - 06
    【Introduction】TMV-700TT vacuum deaeration mixer is a planetary centrifugal mixer mainly applied in mixing fluid or powder material and reach deaeration effect.Rotation/Revolution while working with high power vacuum pump,equipment can stir the material evenly in few seconds or few minutes,stir and vacuum complete at the same timeMixing capacity varies from a few grams up to 700 grams by using different containers, meet the requirement from laboratory use to volume productionUp to 10 preset programs(Can be customized), every program can be divided to 5 segment, each segment with different ...
  • Release time: 2017 - 07 - 06
    【Introduction】TMV-1500TT vacuum deaeration mixer is a planetary centrifugal mixer mainly applied in mixing fluid or powder material and reach deaeration effect. Rotation/Revolution while working with high power vacuum pump,equipment can stir the material evenly in few seconds or few minutes,stir and vacuum complete at the same timeMixing capacity varies from a few grams up to 1500 grams by using different containers, meet the requirement from laboratory use to volume production Up to 10 preset programs(Can be customized), every program can be divided to 5 segment, each segment w...
About Us Introduction

Founded in 2008, Smida is a high-tech company integrating automation solution consultation  R&D, manufacturing, sales, as well as after-sales services. Smida has been granted the trademark registration certificate in Chinese and English and licensed with imports and exports right independently.

Our core team’s members all have more than ten years of industry experiences. Our mission is to become an excellent equipment manufacturer by upholding the principle of “meticulous design and conscientious manufacturing”, and to create value for our customers with quality products and professional services based on win-win cooperation. With all our endeavors, we seek to provide our customers with sustainable services .

Meanwhile, we hold the product quality as our core value . We believe that major manufacturing enterprises will dominate the manufacturing sector in the future and that such enterprises will increasingly resort to automation to meet their production needs. When more and more enterprises use equipment, the stability of the equipment will become very important. At Smida, we take it as our responsibility to design equipment with high stability and easy operation in order to meet the requirements of smart manufacturers.

As our equipment has been tested, purchased in volumes, and used by various major enterprises over a long term, we are confident that it can meet your requirements for quality equipment. So, select us, and you will get professionalism and peace of mind! We are looking forward to hearing from you …
